UHF Reader for Toll ETC – Impinj E710 Module, Model NTS-IR-05
15 m read range · IP66 · Impinj E510 / E710
The NTS-IR-05 is a high-performance UHF integrated reader built on the Impinj IndyE510 chipset (E710 optional), with a read range of up to 15 metres depending on tag and environment.
Its aluminium-cast, waterproof housing suits all-weather industrial use, and it is widely deployed in e-parking, garbage and feeding vehicles, access control and toll ETC.
Key Features
- Reading range: 15 m (depending on tag and environment)
- Impinj IndyE510/E710 (optional) chipset offers high performance
- Aluminium casting / waterproof housing for all-weather industrial scenarios
- Various communication / software interfaces for faster application development
- SDKs in multiple languages to meet different developer needs
- Excellent communication protocol architecture supports faster data processing
- Integrated design for easier deployment, installation, engineering and wiring
- Customised interfaces / data transfer for special application projects
- Seamlessly compatible with RFID middleware for rapid implementation of large projects
- Widely used in e-parking, garbage trucks, feeding vehicles, access control and more
Technical Specification
| Hardware, OS and Firmware Management | |
|---|---|
| Firmware Upgrade | Demo software / Telnet |
| API Support | Windows – .NET, C++ and Java SDK; Android – Java; Linux – C and Java SDK |
| Physical Characteristics | |
| Weight | Main body 1.4 kg |
| Dimensions | 276 mm × 276 mm × 40 mm |
| Housing Material | Aluminium plate / ABS cover |
| RFID Characteristics | |
| Air Protocols | ISO/IEC 18000-6B, 6C / EPC C1 Gen2 |
| Frequency | USA: 902–928 MHz (FCC part 15); EU: 865–868 MHz (ETSI EN 302208); CN: 920–925 MHz (CMIIT) |
| Chipset | Impinj E510 (E710 optional) |
| Programming Functions | Automatic reading / white list; breakpoint resume / match reading / data filter; customizable data format (PLC / Modbus compatible); RF Micron / EM temperature sensor custom services |
| Supportable / Optional | Russia / Japan / Korea / Malaysia / Thailand / other customizable |
| Built-in Antenna | Circular 9 dBi, VSWR ≤ 1.2:1 |
| Output Power | 0–30 dBm (±1 dBm) adjustable |
| Channel Bandwidth | >200 KHz |
| Reading Distance | 0–15 m (according to tag & environment) |
| Anti-collision | RSSI / multi-tag / intensive inventory supported |
| Work Mode | Fixed / hop frequency optional |
| Connectivity | |
| Communications | RJ45, RS-232, RS-485, Wiegand |
| General Purpose I/O | 1 optocoupler input, 1 pair 5V output or Wiegand output (Wiegand output is shared with 5V output) |
| Power Supply | DC 24V / 2.5A (DC 9V ~ 30V, 30W) |
| Environmental | |
| Operating Temperature | -30 to +70°C |
| Storage Temperature | -40 to +85°C |
| Humidity | 5–90% non-condensing (+25°C) |
| Sealing | IP66 |
